ESP32 SIM Modules - Choosing LTE, 3G, GPRS, and GSM Modules

The ESP32 offers robust wireless capabilities, especially the WiFi stack, used to communicate with the outside world. However, in many IoT applications, Wi-Fi alone isn't sufficient, especially when operating in remote or mobile environments where cellular connectivity is essential.

Pairing the ESP32 with a suitable SIM module unlocks advanced capabilities such as cellular connectivity, SMS communication, voice calls, and GNSS-based navigation.

It's worth noting that GSM networks are being phased out in many countries as LTE, NB-IoT, and CAT-M technologies take center stage. While legacy modules like the SIM800 series still hold value for basic projects, newer modules like the SIM7000 or SIM7600G are better suited for future-proof IoT applications. In this guide we will compare popular SIM modules, focusing on their compatibility with ESP32 and how they can address various IoT needs.

Why Use SIM Modules with ESP32? #

Integrating SIM modules with the ESP32 microcontroller significantly enhances connectivity and functionality, particularly in scenarios where Wi-Fi connections are either unreliable or unavailable. Wi-Fi, while widely used, depends on the availability of local networks, which can be a major limitation in remote or rural areas where infrastructure is sparse or non-existent.

In such situations, cellular connectivity provided by SIM modules becomes a crucial alternative, enabling IoT devices to maintain seamless communication regardless of location. By leveraging cellular networks, this integration ensures that devices can send and receive data over long distances without being tied to the proximity of a Wi-Fi access point, making it an ideal solution for applications like remote monitoring, asset tracking, and smart agriculture.

Here are some of the key advantages of using SIM modules with the ESP32:

1. Cellular Connectivity for Remote IoT Applications

SIM modules enable the ESP32 to connect to cellular networks, providing a reliable communication for remote deployments where Wi-Fi or Ethernet may not be feasible. This is especially useful for monitoring and control in remote locations like farms, forests, or industrial sites.

2. SMS and Voice Communication Capabilities

SIM modules allow the ESP32 to send and receive SMS messages and make voice calls, enabling simple and efficient communication for alert systems, customer service bots, and two-way communication setups.

3. GNSS Support for Tracking and Navigation

Many SIM modules (e.g., SIM808, SIM868, SIM7600G) come with GNSS (Global Navigation Satellite System) capabilities. Integrating these modules with the ESP32 enables applications like vehicle tracking, geofencing, and real-time navigation.

4. Low Power Options for Battery-Operated Devices

Modern SIM modules like the SIM7000 and SIM7080G are optimized for low power consumption, making them suitable for battery-operated IoT devices. Combined with the ESP32’s deep sleep modes, these solutions extend the device's operational lifespan in energy-constrained environments.

Overview of SIM Modules Compatible with ESP32 #

When integrating a SIM module with ESP32, it's important to choose the right module based on your project requirements. Here’s an overview of popular SIM modules categorized by their features:

GSM Modules #

These modules are ideal for basic SMS, voice, and data communication over 2G networks. They are cost-effective and widely used in regions where 2G is still operational.

SIM800L: Compact and low-power GSM/GPRS module suitable for SMS, calls, and basic data communication.

Check current price:

SIM800C: Similar to SIM800L but adds Bluetooth functionality for additional connectivity.

Check current price:

SIM800A: Dual-band GSM module for voice and SMS with minimal features, ideal for cost-sensitive projects.

Check current price:

SIM900: Reliable GSM/GPRS module with versatile use cases for SMS, calls, and data applications.

Check current price:

GSM + GPS Modules #

These modules combine GSM capabilities with GPS/GNSS functionality, making them ideal for tracking and navigation applications.

SIM808: A versatile GSM/GPRS + GPS module for vehicle tracking, geofencing, and location-based services.

Check current price:

SIM868: Enhances the SIM808 with GNSS support (GPS, GLONASS, BeiDou), suitable for precise positioning applications.

Check current price:

3G Modules #

While 3G networks are also being phased out in many regions, these modules can serve areas with limited LTE coverage and offer better speeds than GSM.

SIM5320: A 3G WCDMA/HSDPA module with quad-band GSM support. It provides high-speed data (up to 3.6 Mbps) and GPS integration for versatile IoT projects.

Check current price:

IoT-Focused LTE/NB-IoT Modules #

These modules are optimized for low-power IoT applications and support next-generation communication protocols like LTE CAT-M1 and NB-IoT.

SIM7000: Multi-band LTE CAT-M1/NB-IoT module with GNSS support, ideal for IoT sensors and low-power devices.

Check current price:

SIM7080G: A low-power wide-area (LPWA) module designed for NB-IoT and CAT-M applications, featuring rich interfaces and low latency.

Check current price:

High-Speed LTE Modules #

Designed for high-speed data communication, these modules support advanced LTE protocols and are suitable for video streaming and industrial IoT.

A7670: LTE CAT1 module supporting multiple communication modes (LTE-TDD/FDD, GSM). It’s ideal for applications requiring reliable and efficient data transmission.

Check current price:

SIM7600G: A high-performance LTE CAT1 module supporting voice, SMS, high-speed data, and GNSS functionality.

Check current price:

This range of SIM modules is sufficient for diverse IoT needs, from basic GSM communication to advanced LTE and NB-IoT solutions. Choose a module that aligns with your project's requirements for communication protocols, speed, power consumption, and additional features like GNSS or high-speed data.

Key Considerations for SIM Modules Integration with ESP32 #

When choosing a SIM module to integrate with the ESP32, it’s crucial to consider the following factors to ensure seamless operation and optimal performance for your IoT application:

1. Communication Protocols

GSM/GPRS: Best for basic SMS, voice, and low-speed data transmission (e.g., SIM800L, SIM900). Suitable for regions where 2G is still operational.

LTE CAT-M1 and NB-IoT: Ideal for low-power IoT applications requiring long battery life and robust connectivity, even in weak signal areas (e.g., SIM7000, SIM7080G).

LTE: For high-speed data needs, such as video streaming or real-time monitoring (e.g., SIM7600G, A7670).

3G: Provides a balance between data speed and compatibility in areas where 4G is unavailable (e.g., SIM5320).

2. Interfaces

UART: Most SIM modules communicate with ESP32 using UART. Modules like SIM800L and SIM7000 are straightforward to connect via ESP32’s TX and RX pins.

GPIO: Additional GPIO control for functions like power key (PWRKEY) or status monitoring may be required for certain modules.

Antennas: Modules with GNSS (like SIM868 or SIM7600G) may require separate antenna connections for optimal performance.

3. Power Consumption

Low-power Modules: SIM7000 and SIM7080G are optimized for energy efficiency, making them perfect for ESP32 deep sleep-based applications.

Voltage Compatibility: Most modules operate within a range of 3.0V–4.4V. Ensure your power supply can provide stable voltage and adequate current for reliable operation.

4. Features

SMS and Voice: Basic modules like SIM800L or SIM900 are cost-effective for SMS and call-based applications.

Data Communication: High-speed data modules like SIM7600G or A7670 cater to video streaming and IoT dashboards.

GNSS: Modules like SIM808, SIM868, or SIM7600G are essential for tracking and navigation systems.

Comparing the SIM Modules #

Taking the key considerations we talked about above, into account, here’s a comparison table of SIM modules, focusing on how they integrate with ESP32 for various IoT applications:

Communication Protocols: GSM modules like SIM800L or SIM900 are simple and reliable for SMS and voice. IoT-focused modules like SIM7000 and SIM7080G support NB-IoT and LTE CAT-M1, making them ideal for low-power IoT deployments. High-speed LTE modules like A7670 and SIM7600G are suitable for data-intensive tasks.

Interfaces: All modules support UART communication, ensuring compatibility with ESP32. Modules with GNSS functionality (e.g., SIM868, SIM7600G) may require additional antenna connections for location-based applications.

Power Requirements: Modules like SIM7000 and SIM7080G are optimized for low power consumption, making them ideal for ESP32’s deep-sleep mode and battery-operated IoT solutions.

Features: SIM808 and SIM868 combine GPS/GNSS capabilities with GSM, while LTE modules like SIM7600G support advanced functionalities such as high-speed data transfer and GNSS, suiting diverse IoT needs.

General Recommendations for ESP32 Projects #

Choosing the right SIM module is critical to achieving the best performance for your ESP32-based IoT project. Depending on your use case — whether it's a beginner project, a power-efficient IoT deployment, or a high-speed industrial application—the right module can significantly enhance functionality and reliability. Below are some recommendations for SIM modules based on specific project requirements, ensuring an optimal balance between cost, features, and connectivity.

1. Beginner Projects #

• Modules: SIM800L, SIM900
• Why: These are cost-effective and simple to use for basic SMS and low-speed data communication. Ideal for beginners learning ESP32 integration with SIM modules.

2. IoT Applications #

• Modules: SIM7000, SIM7080G
• Why: Optimized for low-power IoT applications with long battery life. These modules support NB-IoT and LTE CAT-M1, ensuring reliable connectivity for remote sensors and devices.

3. Navigation/Tracking #

• Modules: SIM808, SIM868
• Why: Combining GSM/GPRS communication with GPS/GNSS functionality, these modules are perfect for vehicle tracking, asset tracking, and navigation projects.

4. High-Speed Applications #

• Modules: SIM7600G, A7670
• Why: These LTE modules provide high-speed data transfer, multi-band support, and advanced features like GNSS. They are perfect for industrial IoT, video streaming, and real-time monitoring.

Conclusion #

Integrating SIM modules with ESP32 enables diverse IoT applications, from basic SMS communication to advanced industrial systems. Choosing the right module ensures optimal performance for your project needs. For beginner projects, cost-effective modules like SIM800L and SIM900 are great for learning and basic tasks.

IoT applications requiring low power and long battery life are best served by SIM7000 and SIM7080G. Navigation and tracking projects can leverage SIM808 and SIM868 for their robust GNSS capabilities. For high-speed data and industrial IoT, SIM7600G and A7670 provide advanced features and fast connectivity. With the right module, you can build scalable, efficient, and reliable solutions for any IoT challenge.
